| Production |
| Manufacturer: | Farmall (a part of International Harvester)
|
| Factory: | Louisville, Kentucky, USA
|
| Total built: | 2440
|
| Variants |
| Farmall 404: | row-crop chassis
|
| IH 404: | utility chassis
|
| 2404: | industrial
|
| Farmall 404 Power |
| Drawbar (claimed): | 33.4 hp
24.9 kW (gas)
|
| | 29 hp
21.6 kW (LP)
|
| PTO (claimed): | 36.7 hp
27.4 kW (gas)
|
| | 33 hp
24.6 kW (LP)
|
| Plows: | 2-3
|
| Drawbar (tested): | 32.97 hp
24.6 kW
|
| PTO (tested): | 36.70 hp
27.4 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | manual
|
| | power (optional)
|
| Brakes: | differential mechanical disc
|
| Cab: | Open operator station. Optional deluxe deep-cushion seat with padded backrest.
|
| Transmissions: | 4-speed
|
| | 8-speed
|
| | 4-speed manual shuttle
|
| Photos |
| | Farmall 404 photos... |
| Capacity |
| Fuel: | 16.2 gal
61.3 L (gas)
|
| | 19 gal
71.9 L (LP-gas)
|
| Hydraulic system: | 5 gal
18.9 L
|
| Hydraulics |
| Type: | live
|
| Capacity: | 5 gal
18.9 L
|
| Valves: | 1 or 2
|
| Total flow: | 4.5 gpm
17.0 lpm
|
| | 9.3 gpm
35.2 lpm (optional)
|
| Tractor hitch |
| Rear Type: | I
|
| Power Take-off (PTO) |
| Rear PTO: | transmission
|
| Rear RPM: | 540
|
| Dimensions & Tires |
| Wheelbase: | 82.2 inches
208 cm (tricycle)
|
| | 87.8 inches
223 cm (wide front)
|
| Weight: | 3400 to 4115 pounds
|
| Front tire: | 5.00-15
|
| Rear tire: | 11.2-36
|
| 404 Serial Numbers |
| 1961: | 501
|
| 1962: | 826
|
| 1963: | 1936
|
| 1964: | 2259
|
| 1965: | 2568
|
| 1966: | 2790
|
| 1967: | 2980
|
| 1968: | 3170
|
how to read serial numbers...
|
| Belt Pulley |
| Diameter: | 11 inches
27 cm
|
| RPM: | 948
|
| Speed: | 2,730 ft/min
832.10 meters/min
|
|
