| Production |
| Manufacturer: | Farmall (a part of International Harvester)
|
| Total built: | 98,310
|
| Original price: | $1,700 (1954 )
|
| Farmall Super C Power |
| Drawbar (claimed): | 20.7 hp
15.4 kW
|
| PTO (claimed): | 23.67 hp
17.7 kW
|
| Drawbar (tested): | 20.72 hp
15.5 kW
|
| Belt (tested): | 23.67 hp
17.7 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | manual
|
| Brakes: | differential mechanical disc
|
| Cab: | Open operator station.
|
| Transmission: | 4-speed sliding gear
|
| Photos |
| | Farmall Super C photos... |
| Tractor hitch |
| Type: | Fast Hitch*Optional beginning in 1953.
|
| Power Take-off (PTO) |
| Rear RPM: | 540
|
| Dimensions & Tires |
| Wheelbase: | 82.25 inches
208 cm
|
| Weight: | 3100 lbs
1406 kg
|
| Front tire: | 5.00-15
|
| Rear tire: | 10-36
|
| Full dimensions and tires ... |
| Super C Serial Numbers |
| Location: | Seat support frame
|
photo of Super C serial number
| | 1951: | FC100001
|
| 1952: | FC131157
|
| 1953: | FC159130
|
| 1954: | FC187788
|
how to read serial numbers...
|
| Belt Pulley |
| Diameter: | 8.5 inches
21 cm
|
| Width: | 6 inches
15 cm
|
| RPM: | 1363
|
| Speed: | 3,033 ft/min
924.46 meters/min
|
|
