Power: 28 hp Date of manufacture : 1948 - 1951
Production Manufacturer: Ferguson Type: Utility tractor Factory: Detroit, Michigan, USA Ferguson TO-20 Power Drawbar (tested): 20.70 hp 15.4 kW Belt (tested): 25.41 hp 18.9 kW Ferguson TO-20 Engine Mechanical Chassis: 4x2 2WD Steering: manual Brakes: differential mechanical expanding shoe (11x2 inch) Cab: Open operator station. Transmission: 4-speed Photos Ferguson TO-20 photos... Power Take-off (PTO) Rear PTO: transmission Rear RPM: 540 Dimensions & Tires Wheelbase: 70 inches 177 cm Weight: 2,760 lbs 1251 kg Front tire: 4.00-19 Rear tire: 10-28 Full dimensions and tires ... TO-20 Serial Numbers Location: Serial number plate above the TO-20's steering column. photo of TO-20 serial number 1948: 1 1949: 1808 1950: 14660 1951: 39163 Final: 60000 how to read serial numbers... Links TO-20 Profile: information on the Ferguson TO-20 at YTmag.com Electrical Ground: positive Charging system: Delco-Remy 181674M91 Charging amps: 25 Charging volts: 6 Battery volts: 6
