Power: 31 hp Date of manufacture : 1951 - 1954
Production Manufacturer: Ferguson Type: Utility tractor Factory: Detroit, Michigan Ferguson TO-30 Power Drawbar (claimed): 19 hp 14.2 kW PTO (claimed): 28 hp 20.9 kW Drawbar (tested): 24.37 hp 18.2 kW Belt (tested): 29.32 hp 21.9 kW Ferguson TO-30 Engine Mechanical Chassis: 4x2 2WD Steering: manual Brakes: differential mechanical expanding shoe (11x2 inch) Cab: Open operator station. Transmission: 4-speed unsynchronized gear Photos Ferguson TO-30 photos... Power Take-off (PTO) Rear PTO: transmission Rear RPM: 540 Dimensions & Tires Wheelbase: 70 inches 177 cm Weight: 2,800 lbs 1270 kg Front tire: 4.00-19 Rear tire: 10-28 Full dimensions and tires ... TO-30 Serial Numbers Location: Serial number plate on instrument panel. photo of TO-30 serial number 1951: 60001 1952: 72680 1953: 108645 1954: 125929 Final: 140000 how to read serial numbers... Belt Pulley Diameter: 9 inches 22 cm Width: 6.5 inches 16 cm RPM: 1358 Speed: 3207 ft/min 977.49 meters/min Electrical Ground: positive Charging system: Delco-Remy generator 1100529 Charging amps: 25 Charging volts: 6 Battery volts: 6 Battery AH: 80

Ferguson TE-20	Power: 28 hp	Date of manufacture : 1946 - 1948

Ferguson TEA-20	Power: 26 hp	Date of manufacture : 1948 - 1956

Ferguson TEF-20	Power: 28 hp	Date of manufacture : 1951 - 1956

Ferguson TO-20	Power: 28 hp	Date of manufacture : 1948 - 1951

Ferguson TO-30	Power: 31 hp	Date of manufacture : 1951 - 1954

Ferguson TO-35	Power: 36 hp	Date of manufacture : 1954 - 1960

Fiat-Hesston 45-66	Power: 45 hp	Date of manufacture : 0000 - 0000

Fiat-Hesston 55-46	Power: 50 hp	Date of manufacture : 0000 - 0000
