| Production |
| Manufacturer: | Hesston (a part of Fiat)
|
| Type: | Utility tractor
|
| Factory: | Italy
|
| Original price: | $21,550 (1984)
|
| Variants |
| 680: | 2WD
|
| 680DT: | 4WD
|
| Hesston 680 Power |
| PTO (claimed): | 62 hp
46.2 kW
|
| Drawbar (tested): | 53.33 hp
39.8 kW
|
| PTO (tested): | 62.47 hp
46.6 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD (680DT)
|
| Steering: | hydrostatic power
|
| Brakes: | differential hydraulic disc
|
| Cab: | ROPS standard, Supercomfort cab optional with air conditioning. Optional radio, cassette, and CB radio.
|
| Transmissions: | 8-speed partially synchronized
|
| | 16-speed
|
| | 8-speed mechanical shuttle
|
| Hydraulics |
| Type: | open center
|
| Pressure: | 2702 psi
186.3 bar
|
| Valves: | 2
|
| Pump flow: | 11 gpm
41.6 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Rear lift: | 4,410 lbs
2000 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| Dimensions & Tires |
| Wheelbase: | 89 inches
226 cm
|
| Weight: | 5407 to 6029 pounds
|
| Front tire: | 7.50-16
|
| Rear tire: | 16.9-30
|
| Electrical |
| Charging system: | alternator
|
| Charging amps: | 45
|
| | 55 (with cab and A/C)
|
| Battery volts: | 12
|
|
