| Production |
| Manufacturer: | Hesston (a part of Fiat)
|
| Type: | Utility tractor
|
| Original price: | $33,000 (1984)
|
| Variants |
| 880-5: | 2WD
|
| 880-5DT: | 4WD
|
| Hesston 880-5 Power |
| PTO (claimed): | 80 hp
59.7 kW
|
| Drawbar (tested): | 67.78 hp
50.5 kW
|
| PTO (tested): | 81.32 hp
60.6 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD (880-5DT)
|
| Steering: | hydrostatic power
|
| Brakes: | differential hydraulic disc
|
| Cab: | Supercomfort cab standard with air conditioning. Optional radio, cassette, and CB radio.
|
| Transmissions: | 12-speed
|
| | 16-speed
|
| Photos |
| | Hesston 880-5 photos... |
| Hydraulics |
| Type: | open center
|
| Pressure: | 2702 psi
186.3 bar
|
| Valves: | 2
|
| Pump flow: | 11 gpm
41.6 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| Dimensions & Tires |
| Wheelbase: | 96 inches
243 cm
|
| Weight: | 7225 to 8750 pounds
|
| Front tire: | 10.00-16
|
| Rear tire: | 18.4-34
|
| Electrical |
| Charging system: | alternator
|
| Charging amps: | 55
|
|
