International Harvester 654 Tractors

International Harvester 654
Power: 60 hp
Date of manufacture :
1972 - 1974
Production
Manufacturer:International Harvester
Type:Utility tractor
Factory:Neuss, Germany
International Harvester 654 Power
Engine:60 hp
44.7 kW
International Harvester 654 Engine
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:manual
Brakes:dry disc
Cab:Open operator station.
Transmissions:8-speed partially synchronized
 12-speed partial power shift
Capacity
Fuel:18.5 gal
70.0 L
Hydraulic system:4.4 gal
16.7 L
Hydraulics
Capacity:4.4 gal
16.7 L
Tractor hitch
Rear Type:II/I
Rear lift:4410 lbs
2000 kg
Power Take-off (PTO)
Rear RPM:540
 540/1000*Optional
Dimensions & Tires
Wheelbase:83.5 inches
212 cm
Weight:5465 to 6592 pounds
Front tire:6.00-16
Rear tire:12.4/11-36
Full dimensions and tires ...
Electrical
Charging system:generator
Charging amps:11
Charging volts:14
Batteries:2
Battery volts:6
Battery AH:88
