Minneapolis-Moline GTC Tractors
|
|
Power: 0
Date of manufacture : 1951 - 1953 |
Production |
Manufacturer: | Minneapolis-Moline
|
Type: | Standard-tread tractor
|
Factory: | Minneapolis, Minnesota, USA
|
Variants |
GTB: | gasoline
|
GTC: | LP-gas
|
Minneapolis-Moline GTC Power |
Minneapolis-Moline GTC Engine |
Mechanical |
Chassis: | 4x2 2WD
|
Steering: | manual
|
Cab: | Open operator station.
|
Transmission: | 5-speed gear
|
Photos |
| Minneapolis-Moline GTC photos... |
Power Take-off (PTO) |
Rear RPM: | 540
|
Dimensions & Tires |
Wheelbase: | 82.5 inches 209 cm
|
Front tire: | 7.50-18
|
Rear tire: | 14-34
|
Full dimensions and tires ... |
GTC Serial Numbers |
Location: | Right side of tractor frame, just ahead of operator platform.
|
photo of GTC serial number
| 1951: | 04700001
|
1952: | 04700019
|
1953: | 04700677
|
Final: | 04701101
|
how to read serial numbers...
|
Belt Pulley |
Diameter: | 16 inches 40 cm
|
Width: | 7 inches 17 cm
|
RPM: | 627
|
Speed: | 2,630 ft/min 801.62 meters/min
|
|
