Minneapolis-Moline GTB Tractors
 |
|
Power: 60 hp[P]
Date of manufacture : 1947 - 1954 |
| Production |
| Manufacturer: | Minneapolis-Moline
|
| Type: | Standard-tread tractor
|
| Factory: | Minneapolis, Minnesota, USA
|
| Original price: | $2400 (1954 )
|
| Variants |
| GTB: | gasoline
|
| GTC: | LP-gas
|
| GB-D: | diesel
|
| Minneapolis-Moline GTB Power |
| Drawbar (claimed): | 37 hp
27.6 kW
|
| PTO (claimed): | 54 hp
40.3 kW
|
| Drawbar (tested): | 49.53 hp
36.9 kW
|
| Belt (tested): | 58.03 hp
43.3 kW
|
| Minneapolis-Moline GTB Engines |
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | manual
|
| Brakes: | mechanical band
|
| Cab: | Open operator station.
|
| Transmission: | 5-speed gear
|
| Photos |
| | Minneapolis-Moline GTB photos... |
| Power Take-off (PTO) |
| Rear RPM: | 540
|
| Dimensions & Tires |
| Wheelbase: | 82.5 inches
209 cm
|
| Weight: | 6500 lbs
2948 kg
|
| Front tire: | 7.50-18
|
| Rear tire: | 14-34
|
| Full dimensions and tires ... |
| GTB Serial Numbers |
| Location: | Right side of tractor frame, just ahead of operator platform.
|
photo of GTB serial number
| | 1947: | 164001
|
| 1948: | 164179
|
| 1948: | 0164800001
|
| 1949: | 0164900001
|
| 1950: | 016500001
|
| 1951: | 01601864
|
| 1952: | 01603397
|
| 1953: | 01604890
|
| 1954: | 01605973
|
| Final: | 01606289
|
| 1953: | 06800001 (diesel)
|
| 1954: | 06800002 (diesel)
|
| Final: | 06800850 (diesel)
|
how to read serial numbers...
|
| Belt Pulley |
| Diameter: | 16 inches
40 cm
|
| Width: | 7 inches
17 cm
|
| RPM: | 627
|
| Speed: | 2630 ft/min
801.62 meters/min
|
|
