Nuffield Mini 9/16 Tractors

Nuffield Mini 9/16
Power: 16 hp
Date of manufacture :
1965 - 1968
Production
Manufacturer:Nuffield
Type:Utility tractor
Nuffield Mini 9/16 Power
Engine:16 hp
11.9 kW
Nuffield Mini 9/16 Engine
Mechanical
Chassis:4x2 2WD
Final drives:spur gear
Differential lock:mechanical rear
Steering:manual
Cab:Open operator station.
Transmission:9-speed gear
Photos
Nuffield Mini 9/16 photos...
Hydraulics
Pump flow:3 gpm
11.4 lpm
Tractor hitch
Rear Type:I
Rear lift:1000 lbs
453 kg
Power Take-off (PTO)
Rear RPM:540/1000
Dimensions & Tires
Weight:1950 lbs
884 kg
Front tire:4.00x15
Rear tire:9.00x24
Full dimensions and tires ...
Mini 9/16 Serial Numbers
Location:Serial number plate in front of, and below, the seat of the BMC 9/16.
photo of Mini 9/16 serial number
