Navigation: Home > Summit Tractors > TX25H

Summit Tractors TX25H Tractors

Summit Tractors TX25H
Power: 24 hp
Date of manufacture :
0000 - 0000
Production
Distributor:Summit Tractors
Manufacturer:ITL
Type:Compact Utility tractor
Original price:$18,999 (2022, with loader)
Summit Tractors TX25H Power
Engine (gross):24.7 hp
18.4 kW
PTO (claimed):18 hp
13.4 kW
Summit Tractors TX25H Engine
Mechanical
Chassis:4x4 MFWD 4WD
Final drives:mechanical rear
Steering:power
Brakes:wet disc
Cab:Two-post folding ROPS.
Transmission:hydrostatic
Photos
Summit Tractors TX25H photos...
Hydraulics
Type:open center
Rear valves:1
Mid valves:2
Pump flow:4.8 gpm
18.2 lpm
Tractor hitch
Rear Type:I
Control:position control
Rear lift (at ends):1322 lbs
599 kg
Rear lift (at 24"/610mm):1168 lbs
529 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540 (1.375)
Mid PTO:independent
Mid RPM:2100
Dimensions & Tires
Wheelbase:61.8 inches
156 cm
Weight:2513 to 3406 pounds
Electrical
Ground:negative
Charging system:alternator
Charging amps:42
Battery volts:12
