Steiger Wildcat III ST-210 Tractors
|
|
Power: 210 hp
Date of manufacture : 1976 - 1980 |
Production |
Manufacturer: | Steiger
|
Type: | Four-wheel Drive (4WD) tractor
|
Factory: | Fargo, North Dakota, USA
|
Variants |
ST-210: | standard
|
RC-210: | row-crop axles
|
Steiger Wildcat III ST-210 Power |
Engine: | 210 hp 156.6 kW
|
Drawbar (tested): | 163.78 hp 122.1 kW
|
Steiger Wildcat III ST-210 Engine |
Mechanical |
Chassis: | 4x4 articulated 4WD
|
Final drives: | outboard planetary
|
Steering: | articulated power
|
Brakes: | hydraulic disc
|
Cab: | Safari Cab standard with air-conditioning.
|
Transmission: | 10-speed constant mesh
|
Hydraulics |
Type: | open center
|
Pressure: | 2250 psi 155.1 bar
|
Valves: | 2 to 4
|
Pump flow: | 21.7 gpm 82.1 lpm
|
SCV flow: | 8 gpm 30.3 lpm *Minimum
|
| 20 gpm 75.7 lpm *Maximum
|
Tractor hitch |
Rear Type: | III*Optional
|
Dimensions & Tires |
Wheelbase: | 118 inches 299 cm
|
Weight: | 22000 lbs 9979 kg
|
Front tire: | 18.4x34
|
Rear tire: | 18.4x34
|
Full dimensions and tires ... |
Wildcat III ST-210 Serial Numbers |
1976: | 100-00001
|
1977: | 100-00214
|
1978: | 100-00500
|
1979: | 100-00580
|
1980: | 100-00595
|
how to read serial numbers...
|
Electrical |
Ground: | negative
|
Charging system: | alternator
|
Charging amps: | 80
|
Battery volts: | 12
|
Battery AH: | 208
|
|
