Versatile 500 Tractors

Versatile 500
Power: 500 hp
Date of manufacture :
2012 - 2017
Production
Manufacturer:Versatile (a part of Rostselmash)
Type:Four-wheel Drive (4WD) tractor
Factory:Winnipeg, Manitoba, Canada
Versatile 500 Power
Engine:500 hp
372.9 kW
PTO (claimed):400 hp
298.3 kW
Versatile 500 Engine
Mechanical
Chassis:4x4 articulated 4WD
Final drives:outboard planetary
Differential lock:optional
Steering:hydrostatic power
Brakes:dual dry caliper
Cab:Cab standard with air-conditioning.
Transmission:16-speed full power shift
Hydraulics
Type:closed center load sensing (CCLS)
Pressure:2900 psi
200.0 bar
Valves:4 to 6
Pump flow:53 gpm
200.6 lpm
 106 gpm
401.2 lpm (optional)
Tractor hitch
Rear Type:IV
Power Take-off (PTO)
Rear RPM:1000 (1.75)
Dimensions & Tires
Wheelbase:154 inches
391 cm
Weight:42000 lbs
19051 kg
Front tire:710/70R38
Rear tire:710/70R38
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:200
Charging volts:12
Batteries:3
Battery CCA:950
Battery volts:12
