| Production |
| Manufacturer: | Versatile (a part of Rostselmash)
|
| Type: | Four-wheel Drive (4WD) tractor
|
| Factory: | Winnipeg, Manitoba, Canada
|
| Versatile 575 Power |
| Engine: | 575 hp
428.8 kW
|
| Mechanical |
| Chassis: | 4x4 articulated 4WD
|
| Final drives: | outboard planetary
|
| Differential lock: | hydraulic
|
| Steering: | hydrostatic power
|
| Brakes: | dry caliper
|
| Trailer brakes: | hydraulic
|
| Cab: | Deluxe cab standard with air-contidioning, automatic temperature control, and leather seating.
|
| Transmission: | 16-speed full power shift
|
| Photos |
| | Versatile 575 photos... |
| Capacity |
| Fuel: | 350 gal
1324.8 L
|
| Hydraulic system: | 30 gal
113.6 L
|
| Hydraulics |
| Type: | closed center load sensing (CCLS)
|
| Capacity: | 30 gal
113.6 L
|
| Pressure: | 2900 psi
200.0 bar
|
| Valves: | 6
|
| Pump flow: | 80 gpm
302.8 lpm
|
| Tractor hitch |
| Drawbar: | Cat. V
|
| Power Take-off (PTO) |
| Rear PTO: | optional
|
| Rear RPM: | 1000
|
| Dimensions & Tires |
| Wheelbase: | 154 inches
391 cm
|
| Weight: | 45700 lbs
20729 kg
|
| Front tire: | 710/70R42
|
| Rear tire: | 710/70R42
|
| Full dimensions and tires ... |
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 180
|
| Charging volts: | 12
|
| Batteries: | 3
|
| Battery CCA: | 950
|
| Battery volts: | 12
|
|
