| Production |
| Distributor: | AGCO Allis
|
| Manufacturer: | SAME
|
| Type: | Utility tractor
|
| Factory: | Italy
|
| Original price: | $40,000 (1997)
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD (optional)
|
| Differential lock: | mechanical foot-actuated rear
|
| Steering: | hydrostatic power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Cab standard with air-conditioning.
|
| Transmissions: | 12-speed synchromesh
|
| | 24-speed
|
| | 16-speed
|
| | 30-speed partial power shift
|
| Capacity |
| Fuel: | 28.27 gal
107.0 L
|
| Hydraulic system: | 15.2 gal
57.5 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 15.2 gal
57.5 L
|
| Pressure: | 2610 psi
180.0 bar
|
| Valves: | 2
|
| Pump flow: | 11.1 gpm
42.0 lpm
|
| Tractor hitch |
| Rear Type: | II/I
|
| Control: | position and draft control with lower-link sensing
|
| Rear lift (at ends): | 6,790 lbs
3079 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | 124.5mm hydraulic wet disc
|
| Rear RPM: | 540/1000 (1.375)
|
| Engine RPM: | 540@2200
1000@2450
|
| Dimensions & Tires |
| 2WD Wheelbase: | 96.4 inches
244 cm
|
| 4WD Wheelbase: | 92.8 inches
235 cm
|
| Weight: | 6724 to 7385 pounds
|
| Front tire: | 7.50-18
|
| Rear tire: | 16.9R34 (2WD)
|
| Full dimensions and tires ... |
| 6680 Serial Numbers |
| Location: | Console, right side
|
| 1991: | 1001
|
| 1992: | 1147
|
| 1993: | 1157
|
| 1994: | 1242
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 55
|
| Battery volts: | 12
|
| Battery AH: | 100
|
|
