| Production |
| Distributor: | AGCO Allis
|
| Manufacturer: | SAME
|
| Type: | Row-Crop tractor
|
| Factory: | Italy
|
| Original price: | $58,000 (1997)
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD (optional)
|
| Steering: | hydrostatic power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Cab standard with air-conditioning.
|
| Transmissions: | 24-speed partially synchronized
|
| | 36-speed partial power shift
|
| Hydraulics |
| Type: | open center
|
| Valves: | 3
|
| Pump flow: | 15.17 gpm
57.4 lpm
|
| Tractor hitch |
| Rear Type: | II/I
|
| Rear lift: | 9259 lbs
4199 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/540E/1000/1000E
|
| Dimensions & Tires |
| Wheelbase: | 110 inches
279 cm
|
| Weight: | 10,869 lbs
4930 kg
|
| Front tire: | 11.00-16
|
| Rear tire: | 18.4R38 (2WD)
|
| Full dimensions and tires ... |
| 8610 Serial Numbers |
| Location: | Console, right side
|
| 1991: | 1001
|
| 1992: | 1056
|
| 1993: | 1101
|
| 1994: | 1260
|
| 1995: | 1382
|
| 1996: | 1391
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 65
|
| Battery volts: | 12
|
|
