| Production |
| Distributor: | Cabelas
|
| Manufacturer: | TYM
|
| Type: | Compact Utility tractor
|
| Factory: | South Korea
|
| Original price: | $29,499 (2016 gear ROPS )
|
| Original price: | $31,799 (2016 hydro ROPS )
|
| Original price: | $36,399 (2016 hydro cab )
|
| Variants |
| LM55: | shuttle ROPS
|
| LM55H: | hydrostatic ROPS
|
| LM55HC: | hydrostatic cab
|
| Cabelas LM55 Power |
| Engine (gross): | 55.1 hp
41.1 kW
|
| Gear PTO (claimed): | 44.9 hp
33.5 kW
|
| Hydro PTO (claimed): | 42.2 hp
31.5 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Two-post folding ROPS. Cab available with air-conditioning.
|
| Transmissions: | 16-speed synchronized shuttle
|
| | hydrostatic
|
| Capacity |
| Fuel: | 17 gal
64.3 L
|
| Hydraulic system: | 9.25 gal
35.0 L
|
| Front axle: | 10.5 qts
9.9 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 9.25 gal
35.0 L
|
| Valves: | 1
|
| Pump flow: | 9.5 gpm
36.0 lpm *Advertised. During testing, actual flow was 9.2 GPM.
|
| Total flow: | 14.5 gpm
54.9 lpm
|
| Steering flow: | 5 gpm
18.9 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Control: | position and draft control
|
| Rear lift (at ends): | 3314 lbs
1503 kg *Advertised. During testing, actual lift was 2633 pounds.
|
| Rear lift (at 24"/610mm): | 2945 lbs
1335 kg *Advertised. During testing, actual lift was 2472 pounds.
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | electro-hydraulic
|
| Rear RPM: | 540 (1.375)
|
| Dimensions & Tires |
| Wheelbase: | 76.2 inches
193 cm
|
| Weight: | 3924 to 4415 pounds
|
| Front tire: | 9.5-16
|
| Rear tire: | 14.9-24
|
| Full dimensions and tires ... |
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 50
|
| Charging volts: | 12
|
| Battery volts: | 12
|
|
