| Production |
| Manufacturer: | J.I. Case
|
| Type: | Four-wheel Drive (4WD) tractor
|
| Factory: | Racine, Wisconsin, USA
|
| Total built: | 5,900
|
| Original price: | $50,200 (1979 )
|
| J.I. Case 2670 Power |
| Engine (gross): | 256 hp
190.9 kW
|
| Drawbar (claimed): | 193 hp
143.9 kW
|
| PTO (claimed): | 221 hp
164.8 kW
|
| Drawbar (tested): | 189.35 hp
141.2 kW
|
| PTO (tested): | 219.44 hp
163.6 kW
|
| Mechanical |
| Chassis: | 4x4 4WD
|
| Steering: | hydrostatic power, four-wheel steering
|
| Brakes: | hydraulic wet disc
|
| Cab: | Cab standard
|
| Transmission: | 12-speed partial power shift
|
| Photos |
| | J.I. Case 2670 photos... |
| Hydraulics |
| Type: | open center
|
| Pressure: | 2050 psi
141.3 bar
|
| Valves: | 2 to 4
|
| SCV flow: | 17 gpm
64.3 lpm
|
| Total flow: | 34 gpm
128.7 lpm
|
| Steering flow: | 17 gpm
64.3 lpm
|
| Tractor hitch |
| Rear Type: | III
|
| Rear lift (at 24"/610mm): | 10000 lbs
4536 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 1000
|
| Dimensions & Tires |
| Wheelbase: | 102 inches
259 cm
|
| Weight: | 16370 to 20810 pounds
|
| Front tire: | 18.4-34
|
| Rear tire: | 18.4-34
|
| Full dimensions and tires ... |
| 2670 Serial Numbers |
| 1974: | 8762001
|
| 1975: | 8767001
|
| 1976: | 8792901
|
| 1977: | 8825001
|
| 1978: | 8853001
|
| 1979: | 8853001
|
how to read serial numbers...
| |
