Navigation: Home > Case > 400

Case 400 Tractors

Case 400
Power: 55 hp[B]
Date of manufacture :
1955 - 1957
Production
Manufacturer:J.I. Case
Type:Standard-tread tractor
Factory:Racine, Wisconsin, USA
Total built:2,077
Original price:$4,400 (1958)
Mechanical
Chassis:4x2 2WD
Steering:manual
 power optional
Brakes:mechanical dry discs
Cab:Open operator station.
Transmission:8-speed
Photos
J.I. Case 400 photos...
Capacity
Fuel:21 gal
79.5 L
Hydraulic system:2.25 gal
8.5 L
 2.6 gal
9.8 L (with Eagle Hitch)
Hydraulics
Capacity:2.25 gal
8.5 L
 2.6 gal
9.8 L (with Eagle Hitch)
Pressure:600 psi
41.4 bar
Valves:2 (optional)
Total flow:12 gpm
45.4 lpm
Tractor hitch
Type:Case Eagle Hitch
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Dimensions & Tires
Wheelbase:82 inches
208 cm
Weight:5600 to 6000 pounds
Front tire:6.00-16
Rear tire:13-30
Full dimensions and tires ...
400 Serial Numbers
Location:Top-right of instrument panel.
photo of 400 serial number

1955:8060000
1956:8080001
1957:8100001

how to read serial numbers...

Belt Pulley
Diameter:10.5 inches
26 cm
Width:7.25 inches
18 cm
RPM:1128
Speed:3,101 ft/min
945.18 meters/min
Electrical
Ground:negative
Charging system:generator
Charging volts:12
Batteries:2
Battery volts:6
Battery AH:150
