| Production |
| Manufacturer: | J.I. Case
|
| Type: | Row-Crop tractor
|
| Factory: | Rock Island, Illinois, USA
|
| Original price: | $3,300 (1960 )
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | manual
|
| Brakes: | differential mechanical dry disc
|
| Cab: | Open operator station.
|
| Transmissions: | 8-speed torque converter
|
| | 4-speed torque converter
|
| Photos |
| | J.I. Case 411-B photos... |
| Capacity |
| Fuel: | 13.8 gal
52.2 L
|
| Hydraulic system: | 3 gal
11.4 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 3 gal
11.4 L
|
| Pressure: | 1200 psi
82.7 bar
|
| Tractor hitch |
| Type: | Eagle Hitch
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540 (1.375)
|
| Engine RPM: | 541@1970
|
| Dimensions & Tires |
| Wheelbase: | 84.5 inches
214 cm (tricycle)
|
| | 79.5 inches
201 cm (GP)
|
| Weight: | 4349 lbs
1972 kg
|
| Front tire: | 5.50-16
|
| Rear tire: | 11-28
|
| 411-B Serial Numbers |
| Location: | Serial number plate on the left side of the tractor's instrument panel.
|
photo of 411-B serial number
|
| Belt Pulley |
| Diameter: | 10.25 inches
26 cm
|
| Width: | 6 inches
15 cm
|
| RPM: | 1180
|
| Speed: | 3060 ft/min
932.69 meters/min
|
| Electrical |
| Ground: | positive
|
| Charging system: | generator
|
| Battery volts: | 12
|
| Battery AH: | 50
|
|
