Navigation: Home > Case > 4994

Case 4994 Tractors

Case 4994
Power: 400 hp
Date of manufacture :
1984 - 0000
Production
Manufacturer:J.I. Case
Type:Four-wheel Drive (4WD) tractor
Factory:Racine, Wisconsin, USA
Total built:224
Original price:$132,050 (1985)
J.I. Case 4994 Power
Engine:400 hp
298.3 kW
PTO (claimed):344 hp
256.5 kW
Drawbar (tested):294.24 hp
219.4 kW
PTO (tested):344 hp
256.5 kW
J.I. Case 4994 Engine
Mechanical
Chassis:4x4 4WD
Steering:hydraulic, front, rear or four-wheel crab steering
Brakes:hydraulic dual caliper disc
Cab:Silent Guardian cab standard
Transmission:12-speed full power shift
Photos
J.I. Case 4994 photos...
Capacity
Fuel:300 gal
1135.5 L
Hydraulic system:26.25 gal
99.4 L
Front hubs:13.5 qts
12.8 L (each)
Front diff.:17 qts
16.1 L
Rear hubs:13.5 qts
12.8 L (each)
Rear diff.:22.5 qts
21.3 L
Hydraulics
Type:closed center
Capacity:26.25 gal
99.4 L
Pressure:2000 psi
137.9 bar
Valves:2 to 4
Pump flow:35 gpm
132.5 lpm
Total flow:35 gpm
132.5 lpm
Steering flow:20 gpm
75.7 lpm
Steering press.:2000 psi
137.9 bar
Tractor hitch
Rear Type:IV/IVN (optional)
Rear lift (at 24"/610mm):16,000 lbs
7257 kg
Power Take-off (PTO)
Rear PTO:independent (optional)
Rear RPM:1000
Engine RPM:1000@2100
Dimensions & Tires
Wheelbase:124.8 inches
316 cm
Weight:26500 to 31315 pounds
Front tire:24.5-32
Rear tire:24.5-32
Full dimensions and tires ...
4994 Serial Numbers
Location:Data plates located at forward-right corner in top of the tractor cab.
1984:8865000

how to read serial numbers...

Electrical
Ground:negative
Charging system:alternator
Charging amps:105
Batteries:2
Battery volts:12
Battery AH:300
Battery Group:30H
