| Production |
| Manufacturer: | J.I. Case
|
| Type: | Standard-tread tractor
|
| Factory: | Racine, Wisconsin, USA
|
| Original price: | $6,000 (1969 )
|
| Variants |
| 830: | diesel standard-front
|
| 831: | diesel row-crop
|
| 832: | diesel Western Special
|
| 833: | diesel high-crop
|
| 840: | gas standard-front
|
| 841: | gas row-crop
|
| 842: | gas Western Special
|
| 843: | gas high-crop
|
| J.I. Case 830 Power |
| Belt (claimed): | 66 hp
49.2 kW
|
| Plows: | 5
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | power assist
|
| Brakes: | mechanical dry disc
|
| Cab: | Open operator station.
|
| Transmissions: | 8-speed gear
|
| | 8-speed torque converter
|
| Photos |
| | J.I. Case 830 photos... |
| Capacity |
| Fuel: | 22 gal
83.3 L
|
| Hydraulic system: | 17 gal
64.3 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 17 gal
64.3 L
|
| Pressure: | 1550 psi
106.9 bar
|
| Tractor hitch |
| Rear Type: | II
|
| Control: | Draft-o-matic load/depth control
|
| Type: | Case Eagle Hitch
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000 (1.375)
|
| Dimensions & Tires |
| Wheelbase: | 82.75 inches
210 cm
|
| Weight: | 5694 to 5837 pounds
|
| Front tire: | 6.00-16
|
| Rear tire: | 13-30
|
| Full dimensions and tires ... |
| 830 Serial Numbers |
| Location: | Plate on instrument panel
|
| 1960: | 8160001
|
| 1961: | 8168801
|
| 1962: | 8190001
|
| 1963: | 8208001
|
| 1964: | 8229001
|
| 1965: | 8253501
|
| 1966: | 8279001
|
| 1967: | 8306501
|
| 1968: | 8332101
|
| 1969: | 8356251
|
how to read serial numbers...
|
| Belt Pulley |
| Diameter: | 10.5 inches
26 cm
|
| Width: | 7.25 inches
18 cm
|
| RPM: | 1322 (Dual Range)
|
| | 1027 (Case-O-Matic 540)
|
| | 1261 (Case-O-Matic 1000)
|
| Electrical |
| Ground: | negative
|
| Charging system: | generator
|
| Batteries: | 2
|
| Battery volts: | 6
|
|
