Case 885 Tractors

Case 885
Power: 47 hp
Date of manufacture :
1976 - 1980
Production
Manufacturer:J.I. Case
Type:Utility tractor
Factory:Meltham Mills, Huddersfield, England
Original price:$7,400 (1976)
J.I. Case 885 Power
Engine (net):47.3 hp
35.3 kW
Drawbar (claimed):37 hp
27.6 kW
PTO (claimed):43 hp
32.1 kW
Drawbar (tested):36.56 hp
27.3 kW
PTO (tested):43.20 hp
32.2 kW
J.I. Case 885 Engines
Mechanical
Chassis:4x2 2WD
Steering:manual
 hydrostatic power (optional)
Brakes:differential mechanical drum
Cab:Cab optional.
Transmission:12-speed partially synchronized
Capacity
Fuel:12.7 gal
48.1 L
Hydraulic system:6 gal
22.7 L
Hydraulics
Type:open
Capacity:6 gal
22.7 L
Pressure:2000 psi
137.9 bar
Total flow:7.4 gpm
28.0 lpm
Tractor hitch
Rear Type:I, II
Rear lift:1,800 lbs
816 kg (recommended)
 3,450 lbs
1564 kg (max)
Power Take-off (PTO)
Rear RPM:540/1000
Dimensions & Tires
Wheelbase:77 inches
195 cm
Weight:4,265 lbs
1934 kg
Front tire:6.00-16
Rear tire:14.9-28
Full dimensions and tires ...
885 Serial Numbers
Location:On the right front side of the frame
1971:620001
1972:620336
1973:624731
1974:630611
1975:634830
1976:11000001
1977:11005148
1978:11011088
1979:11015095
1980:11019389

how to read serial numbers...

Electrical
Charging system:alternator
Battery volts:12
Battery AH:86
