| Production |
| Manufacturer: | J.I. Case
|
| Type: | Utility tractor
|
| Factory: | Meltham Mills, Huddersfield, England
|
| Original price: | $10,500 (1976 )
|
| Variants |
| 995: | live PTO foot clutch
|
| 996: | independent PTO hand clutch
|
| J.I. Case 995 Power |
| Engine (gross): | 62 hp
46.2 kW
|
| PTO (claimed): | 58 hp
43.3 kW
|
| Drawbar (tested): | 48.73 hp
36.3 kW
|
| PTO (tested): | 58.77 hp
43.8 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Final drives: | spur gear
|
| Steering: | power
|
| Brakes: | hydraulic drum
|
| Cab: | Open operator station. Quiet Cab optional.
|
| Transmission: | 12-speed synchromesh
|
| Photos |
| | J.I. Case 995 photos... |
| Hydraulics |
| Type: | open center
|
| Pump flow: | 7.4 gpm
28.0 lpm
|
| Tractor hitch |
| Rear Type: | II/I
|
| Rear lift: | 2000 lbs
907 kg
|
| Power Take-off (PTO) |
| Rear PTO: | live
|
| Rear RPM: | 540/1000
|
| Engine RPM: | 540@1800
1000@2000
|
| Dimensions & Tires |
| Wheelbase: | 82 inches
208 cm
|
| Weight: | 4780 to 5190 pounds
|
| Front tire: | 7.50-16
|
| Rear tire: | 13.6/12-36
|
| Full dimensions and tires ... |
| 995 Serial Numbers |
| Location: | On front frame, right side.
|
| 1971: | 920001
|
| 1972: | 921383
|
| 1973: | 925158
|
| 1974: | 928575
|
| 1975: | 931772
|
| 1976: | 11070001
|
| 1977: | 11080236
|
| 1978: | 11089141
|
| 1979: | 11096828
|
| 1980: | 11104577
|
how to read serial numbers...
|
| Electrical |
| Charging system: | alternator
|
| Battery volts: | 12
|
| Battery AH: | 96
|
|
