CaseIH 235 Tractors

CaseIH 235
Power: 18 hp
Date of manufacture :
1986 - 1990
Production
Distributor:CaseIH
Manufacturer:Mitsubishi
Type:Compact Utility tractor
Original price:$10,000 (1990 )
CaseIH 235 Power
Engine:18 hp
13.4 kW
PTO (claimed):15.2 hp
11.3 kW
CaseIH 235 Engine
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Brakes:mechanical drum
Cab:Two-post folding ROPS. Optional canopy.
Transmissions:6-speed
 hydrostatic
Capacity
Fuel:4.8 gal
18.2 L
Hydraulic system:3.1 gal
11.7 L
Hydraulics
Capacity:3.1 gal
11.7 L
Valves:0 or 1
Total flow:3.4 gpm
12.9 lpm
Tractor hitch
Rear Type:I
Rear lift (at ends):1,035 lbs
469 kg
Rear lift (at 24"/610mm):816 lbs
370 kg
Power Take-off (PTO)
Gear Rear PTO:transmission
Hydro Rear PTO:live
Rear RPM:540
Mid PTO:live*Optional with hydrostatic
Mid RPM:2400
Front RPM:2700*Optional
Dimensions & Tires
Wheelbase:56 inches
142 cm
Weight:1350 to 1537 pounds
Front tire:4.50-10
Rear tire:8.00-18
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:35
Battery volts:12
