| Production |
| Distributor: | CaseIH
|
| Manufacturer: | Mitsubishi
|
| Type: | Compact Utility tractor
|
| Original price: | $11,000 (1990 )
|
| CaseIH 245 Power |
| Engine: | 21 hp
15.7 kW
|
| PTO (claimed): | 18 hp
13.4 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | manual
|
| | power optional
|
| Brakes: | mechanical drum
|
| Cab: | Two-post folding ROPS. Optional sun shade.
|
| Transmissions: | 9-speed constant mesh
|
| | 9-speed synchromesh
|
| Photos |
| | CaseIH 245 photos... |
| Capacity |
| Fuel: | 5.5 gal
20.8 L
|
| Hydraulic system: | 6.6 gal
25.0 L
|
| Hydraulics |
| Capacity: | 6.6 gal
25.0 L
|
| Valves: | 0 or 1
|
| Total flow: | 4.5 gpm
17.0 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift (at ends): | 1,500 lbs
680 kg
|
| Rear lift (at 24"/610mm): | 1,125 lbs
510 kg
|
| Power Take-off (PTO) |
| Rear PTO: | transmission
|
| | live*Optional
|
| Rear RPM: | 540,1150
|
| Mid PTO: | live
|
| Mid RPM: | 2400*Optional
|
| Dimensions & Tires |
| Wheelbase: | 65.9 inches
167 cm
|
| Weight: | 1910 lbs
866 kg
|
| Front tire: | 4.00-15
|
| Rear tire: | 9.5-24
|
| Full dimensions and tires ... |
| 245 Serial Numbers |
| Location: | Serial number plate on the front-right of the Case IH 245 tractor frame.
|
| 1986: | 17636500
|
| 1987: | 17637276
|
| 1988: | 0009001
|
| 1989: | 0009993
|
| 1990: | 0010844
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 35
|
| Battery volts: | 12
|
|
