Power: 202 hp[P] Date of manufacture : 1985 - 1988
Production Manufacturer: CaseIH Type: Row-Crop tractor Factory: Racine, Wisconsin, USA Original price: $75,000 (1987 ) CaseIH 3594 Power PTO (claimed): 182 hp 135.7 kW Drawbar (tested): 160.39 hp 119.6 kW PTO (tested): 182.27 hp 135.9 kW CaseIH 3594 Engine Mechanical Chassis: 4x4 MFWD 4WD Steering: power Brakes: differential hydraulic wet disc Cab: Cab standard Transmissions: 24-speed partial power shift   12-speed partial power shift Capacity Fuel: 85 gal 321.7 L Hydraulic system: 33.25 gal 125.9 L Hydraulics Type: closed center Capacity: 33.25 gal 125.9 L Pressure: 2250 psi 155.1 bar Valves: 2 to 4 Pump flow: 30 gpm 113.6 lpm Tractor hitch Rear Type: III Rear lift (at 24"/610mm): 7750 lbs 3515 kg Power Take-off (PTO) Rear PTO: independent Rear RPM: 1000 Dimensions & Tires Wheelbase: 116 inches 294 cm Weight: 17590 lbs 7978 kg Front tire: 16.9-26 Rear tire: 24.5R-32 Full dimensions and tires ... 3594 Serial Numbers Location: Inside cab 1985: 9938100 1986: 9941573 1987: 9945448 1988: 9948517 how to read serial numbers... Electrical Ground: negative Charging system: alternator Charging amps: 105

CaseIH 3220	Power: 53 hp	Date of manufacture : 1994 - 1997

CaseIH 3230	Power: 60 hp	Date of manufacture : 1994 - 1997

CaseIH 3294	Power: 197 hp	Date of manufacture : 1985 - 1986

CaseIH 3394	Power: 180 hp[P]	Date of manufacture : 1985 - 1987

CaseIH 3594	Power: 202 hp[P]	Date of manufacture : 1985 - 1988

CaseIH 4210	Power: 72 hp	Date of manufacture : 1994 - 1997

CaseIH 4230	Power: 84 hp	Date of manufacture : 1994 - 1997

CaseIH 4240	Power: 104 hp	Date of manufacture : 1994 - 1997

CaseIH 4494	Power: 213 hp	Date of manufacture : 1984 - 1987
