| Production |
| Manufacturer: | CaseIH
|
| Type: | Four-wheel Drive (4WD) tractor
|
| Factory: | Fargo, North Dakota, USA
|
| Original price: | $119,000 (1995)
|
| CaseIH 9270 Power |
| Engine: | 335 hp
249.8 kW
|
| PTO (claimed): | 308 hp
229.7 kW
|
| Drawbar (tested): | 264.77 hp
197.4 kW
|
| PTO (tested): | 317.50 hp
236.8 kW
|
| Mechanical |
| Chassis: | 4x4 articulated 4WD
|
| Steering: | hydrostatic power
|
| Brakes: | integrated hydraulic wet disc
|
| Cab: | Cab standard with air-conditioning. Optional deluxe cab adds side and rear windowwipers plus internal storage compartments.
|
| Transmissions: | 12-speed full power shift
|
| | 12-speed fully synchronized
|
| Capacity |
| Fuel: | 250 gal
946.3 L
|
| Hydraulic system: | 26 gal
98.4 L
|
| Hydraulics |
| Type: | closed center load sensing pressure compensating
|
| Capacity: | 26 gal
98.4 L
|
| Pressure: | 2500 psi
172.4 bar
|
| Valves: | 4
|
| Powershift Total flow: | 27 gpm
102.2 lpm
|
| SyncroShift Total flow: | 30 gpm
113.6 lpm
|
| Tractor hitch |
| Optional Rear Type: | III
|
| Rear lift: | 14,000 lbs
6350 kg
|
| Power Take-off (PTO) |
| Optional Rear PTO: | independent
|
| Rear RPM: | 1000
|
| Engine RPM: | 1000@2098
|
| Dimensions & Tires |
| Wheelbase: | 141.5 inches
359 cm
|
| Weight: | 34,045 lbs
15442 kg
|
| Front tire: | 24.5-32
|
| Rear tire: | 24.5-32
|
| Full dimensions and tires ... |
| 9270 Serial Numbers |
| Location: | Under the left-side steps on front fender
|
| 1990: | JCB0004600
|
| 1991: | JCB0026501
|
| 1992: | JCB0028400
|
| 1993: | JCB0030500
|
| 1994: | JEE0031773
|
| 1995: | JEE0032808
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Battery volts: | 12
|
|
