| Production |
| Manufacturer: | CaseIH
|
| Type: | Four-wheel Drive (4WD) tractor
|
| Factory: | Fargo, North Dakota, USA
|
| Original price: | $105,000 (1995)
|
| Mechanical |
| Chassis: | 4x4 4WD
|
| Steering: | four-wheel hydrostatic power
|
| Brakes: | integrated hydraulic caliper disc
|
| Cab: | Cab standard with air-conditioning. Optional deluxe cab adds side and rear windowwipers plus internal storage compartments.
|
| Transmission: | 12-speed full power shift
|
| Capacity |
| Fuel: | 200 gal
757.0 L
|
| Hydraulic system: | 18 gal
68.1 L
|
| Hydraulics |
| Type: | closed center load sensing pressure compensting
|
| Capacity: | 18 gal
68.1 L
|
| Pressure: | 2500 psi
172.4 bar
|
| Valves: | 4
|
| Total flow: | 28 gpm
106.0 lpm
|
| Tractor hitch |
| Optional Rear Type: | III
|
| Control: | optional
|
| Rear lift: | 12,750 lbs
5783 kg
|
| Power Take-off (PTO) |
| Optional Rear PTO: | independent
|
| Rear RPM: | 1000
|
| Engine RPM: | 1000@2098
|
| Dimensions & Tires |
| Wheelbase: | 124 inches
314 cm
|
| Weight: | 28,214 lbs
12797 kg
|
| Front tire: | 18.4-38
|
| Rear tire: | 18.4-38
|
| Full dimensions and tires ... |
| 9240 Serial Numbers |
| Location: | Under the left-side steps on front fender
|
| 1990: | JCB0004600
|
| 1991: | JCB0026501
|
| 1992: | JCB0028400
|
| 1993: | JCB0030500
|
| 1994: | JEE0031773
|
| 1995: | JEE0032808
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Battery volts: | 12
|
|
