| Production |
| Manufacturer: | CaseIH
|
| Type: | Four-wheel Drive (4WD) tractor
|
| Factory: | Fargo, North Dakota, USA
|
| Original price: | $139,000 (1999 )
|
| Variants |
| 9370: | wheeled tractor
|
| 9370QT: | Quadtrac crawler
|
| CaseIH 9370 Power |
| Engine (gross): | 360 hp
268.5 kW
|
| PTO (claimed): | 310 hp
231.2 kW
|
| Drawbar (tested): | 286.17 hp
213.4 kW
|
| PTO (tested): | 330.65 hp
246.6 kW
|
| Mechanical |
| Chassis: | 4x4 articulated 4WD
|
| Steering: | articulated power
|
| Brakes: | hydraulic disc
|
| Cab: | Cab standard with air-conditioning.
|
| Transmissions: | 12-speed full powershift
|
| | 12-speed
|
| | 24-speed
|
| Photos |
| | CaseIH 9370 photos... |
| Hydraulics |
| Type: | closed center
|
| Pressure: | 2900 psi
200.0 bar
|
| Valves: | 4
|
| Pump flow: | 27 gpm
102.2 lpm (Power shift)
|
| | 30 gpm
113.6 lpm (Synchro shift)
|
| Steering flow: | 31 gpm
117.3 lpm (Power shift)
|
| | 34 gpm
128.7 lpm (Synchro shift)
|
| Tractor hitch |
| Rear Type: | IV
|
| Rear lift (at 24"/610mm): | 17000 lbs
7711 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 1000
|
| Dimensions & Tires |
| Wheelbase: | 144 inches
365 cm
|
| Weight: | 33786 lbs
15325 kg
|
| Front tire: | 20.8R-38
|
| Rear tire: | 20.8R-38
|
| Full dimensions and tires ... |
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 125
|
| Batteries: | 3
|
| Battery CCA: | 625
|
| Battery volts: | 12
|
|
