| Production |
| Manufacturer: | CaseIH
|
| Type: | Utility tractor
|
| Factory: | Doncaster, England
|
| Original price: | $32,200 (1999)
|
| Variants |
| CX90: | deluxe model
|
| C90: | basic model
|
| CaseIH CX90 Power |
| Engine (gross): | 90 hp
67.1 kW
|
| Engine (net): | 84 hp
62.6 kW
|
| PTO (claimed): | 74 hp
55.2 kW
|
| Drawbar (tested): | 69.2 hp
51.6 kW
|
| PTO (tested): | 79.7 hp
59.4 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD (optional)
|
| Differential lock: | electro-hydraulic
|
| Steering: | hydrostatic power
|
| Brakes: | differential hydraulic wet disc
|
| Cab: | Two-post ROPS with flat platform. Optional cab with air-conditioning.
|
| Transmissions: | 8-speed synchro shuttle
|
| | 16-speed partial power shift
|
| | 24-speed creeper
|
| Photos |
| | CaseIH CX90 photos... |
| Capacity |
| Fuel: | 42 gal
159.0 L
|
| Hydraulic system: | 9.1 gal
34.4 L (2WD)
|
| | 9.8 gal
37.1 L (4WD)
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 9.1 gal
34.4 L (2WD)
|
| | 9.8 gal
37.1 L (4WD)
|
| Pressure: | 2500 psi
172.4 bar
|
| Valves: | 0 to 3
|
| Pump flow: | 15.7 gpm
59.4 lpm
|
| Total flow: | 24.2 gpm
91.6 lpm (total)
|
| | 15.7 gpm
59.4 lpm (main pump)
|
| | 8.5 gpm
32.2 lpm (lube pump)
|
| Tractor hitch |
| Rear Type: | II/I
|
| Control: | electronic upper link
|
| Rear lift: | 3,665 lbs
1662 kg
|
| | 5,097 lbs
2311 kg (optional)
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | hydraulic wet disc
|
| Rear RPM: | 540
|
| | 540/1000 (optional dual shaft)
|
| Dimensions & Tires |
| Wheelbase: | 92.3 inches
234 cm (2WD)
|
| | 93.7 inches
237 cm (4WD)
|
| Weight: | 7396 to 8466 pounds
|
| Front tire: | 7.50-16
|
| Rear tire: | 16.9-30
|
| Full dimensions and tires ... |
| CX90 Serial Numbers |
| Location: | Near the tractor steering column on right side.
|
| 1998: | JJE1000056
|
| 1999: | JJE1008492
|
| 2000: | JJE1013490
|
| 2001: | JJE1017672
|
| 2002: | JJE1019985
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 65
|
| Battery CCA: | 650
|
| | 810 (optional)
|
| Battery volts: | 12
|
|
