| Production |
| Manufacturer: | CaseIH
|
| Type: | Compact Utility tractor
|
| Variants |
| D40: | shuttle
|
| DX40: | hydrostatic
|
| CaseIH D40 Power |
| Engine (gross): | 40 hp
29.8 kW
|
| PTO (claimed): | 35 hp
26.1 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | mechanical wet disc
|
| Cab: | Two-post ROPS. Foldable ROPS optional. Optional canopy, soft cab, and radio.
|
| Transmission: | 12-speed synchronized shuttle
|
| Hydraulics |
| Valves: | 1 or 2
|
| Pump flow: | 9.8 gpm
37.1 lpm
|
| Total flow: | 14.9 gpm
56.4 lpm
|
| Steering flow: | 5.1 gpm
19.3 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift (at 24"/610mm): | 2,330 lbs
1056 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| Mid PTO: | optional
|
| Mid RPM: | 2000
|
| Dimensions & Tires |
| Wheelbase: | 73.5 inches
186 cm
|
| Weight: | 2998 to 3147 pounds
|
| Front tire: | 5.50x16
|
| Rear tire: | 13.6x24
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 40
|
| Battery CCA: | 600
|
| Battery volts: | 12
|
|
