Chamberlain 4090 Tractors
 |
|
Power: 100 hp
Date of manufacture : 1985 - 1986 |
| Production |
| Manufacturer: | Chamberlain (a part of John Deere)
|
| Type: | Row-Crop tractor
|
| Factory: | Welshpool, Australia
|
| Total built: | 510
|
| Chamberlain 4090 Power |
| Engine (net): | 100.5 hp
74.9 kW
|
| PTO (claimed): | 94 hp
70.1 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD (optional)
|
| Steering: | hydrostatic power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Cab standard with air-conditioning.
|
| Transmission: | 12-speed partial power shift
|
| Photos |
| | Chamberlain 4090 photos... |
| Capacity |
| Fuel: | 57.3 gal
216.9 L
|
| Hydraulic system: | 7.2 gal
27.3 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 7.2 gal
27.3 L
|
| Pressure: | 2500 psi
172.4 bar
|
| Valves: | 4 (max)
|
| | 3 (with 3pt)
|
| Total flow: | 15.6 gpm
59.0 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Control: | top-link sensing
|
| Rear lift (at 24"/610mm): | 5,355 lbs
2429 kg
|
| | 6,517 lbs
2956 kg (optional)
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | hydraulic disc
|
| Rear RPM: | 540
|
| | 1000 (optional)
|
| Dimensions & Tires |
| 2WD fixed Wheelbase: | 104.2 inches
264 cm
|
| | 104.9 inches
266 cm (2WD)
|
| | 112.4 inches
285 cm (4WD)
|
| Weight: | 11671 to 12302 pounds
|
| Front tire: | 11.00x16
|
| Rear tire: | 23.1x34 (2WD)
|
| Full dimensions and tires ... |
| Electrical |
| Charging system: | alternator
|
| Charging amps: | 55
|
| Batteries: | 2
|
| Battery volts: | 6
|
|
