Cletrac W 12-20 Tractors

Cletrac W 12-20
Power: 22 hp
Date of manufacture :
1919 - 1932
Production
Manufacturer:Cletrac
Type:Agricultural Crawler tractor
Factory:Cleveland, Ohio, USA
Cletrac W 12-20 Power
Drawbar (claimed):12 hp
8.9 kW
Belt (claimed):20 hp
14.9 kW
Plows:3 (12-inch)
Drawbar (tested):15.52 hp
11.6 kW
Belt (tested):24.94 hp
18.6 kW
Cletrac W 12-20 Engine
Mechanical
Chassis:crawler
Cab:Open operator station.
Transmission:1-speed gear
Photos
Cletrac W 12-20 photos...
Dimensions & Tracks
Weight:3455 lbs
1567 kg
8-inch tracks
Full dimensions and tracks ...
Belt Pulley
Diameter:8 inches
20 cm
Width:6 inches
15 cm
RPM:1265
Speed:2500 ft/min
762.00 meters/min
