| Production |
| Manufacturer: | Cockshutt
|
| Type: | Row-Crop tractor
|
| Factory: | Charles City, Iowa, USA
|
| Original price: | $5,900 (1964 )
|
| Cockshutt 1800 Power |
| Drawbar (tested): | 68.40 hp
51.0 kW
|
| PTO (tested): | 80.72 hp
60.2 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | power assist
|
| | hydrostatic power (Series C)
|
| Brakes: | disc
|
| Cab: | Open operator station.
|
| Transmissions: | 6-speed gear
|
| | 12-speed partial power shift
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| Dimensions & Tires |
| Wheelbase: | 109.25 inches
277 cm
|
| Weight: | 9205 to 10675 pounds
|
| Front tire: | 7.50-15
|
| Rear tire: | 18.4-34
|
| Full dimensions and tires ... |
| 1800 Serial Numbers |
| Location: | Serial plate on instrument panel.
|
| 1962: | 124 397 (Series B)
|
| 1963: | 129 286 (Series B)
|
| Final: | 134 683 (Series B)
|
| 1963: | 129 286 (Series C)
|
| 1964: | 140 893 (Series C)
|
| Final: | 149 818 (Series C)
|
how to read serial numbers...
| |
