| Production |
| Manufacturer: | Cockshutt
|
| Type: | Row-Crop tractor
|
| Factory: | Charles City, Iowa, USA
|
| Original price: | $9,000 (1964 )
|
| Cockshutt 1900 Power |
| Drawbar (tested): | 88.27 hp
65.8 kW
|
| PTO (tested): | 100.62 hp
75.0 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | manual
|
| | power (late)
|
| Brakes: | differential dry disc
|
| Cab: | Open operator station.
|
| Transmissions: | 6-speed unsynchronized gear
|
| | 12-speed partial power shift
|
| Photos |
| | Cockshutt 1900 photos... |
| Capacity |
| Fuel: | 31.5 gal
119.2 L
|
| Hydraulic system: | 5 gal
18.9 L
|
| Hydraulics |
| Capacity: | 5 gal
18.9 L
|
| Pump flow: | 13 gpm
49.2 lpm
|
| Tractor hitch |
| Rear Type: | II/I
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| | 1000
|
| Engine RPM: | 1000@2000
|
| Dimensions & Tires |
| Wheelbase: | 97.25 inches
247 cm
|
| Weight: | 12000 lbs
5443 kg
|
| Front tire: | 7.50-18
|
| Rear tire: | 18-26
|
| Full dimensions and tires ... |
| 1900 Serial Numbers |
| Location: | Serial plate on instrument panel.
|
| 1960: | 90-532 (A)
|
| 1961: | 111-028 (A)
|
| 1962: | 118-356 (A)
|
| 1962: | 124-396 (B)
|
| 1963: | 128-422 (B)
|
| 1963: | 138-440 (C)
|
| 1964: | 141-168 (C)
|
| Final: | 148-651 (C)
|
how to read serial numbers...
| |
