Deutz-Allis 6070 Tractors
 |
|
Power: 78 hp[P]
Date of manufacture : 1985 - 1988 |
| Production |
| Manufacturer: | Deutz-Allis
|
| Type: | Row-Crop tractor
|
| Factory: | West Allis, Wisconsin, USA
|
| Total built: | 972
|
| Original price: | $24,225
|
| Deutz-Allis 6070 Power |
| Drawbar (tested): | 58.35 hp
43.5 kW
|
| PTO (tested): | 70.78 hp
52.8 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD (optional)
|
| Steering: | hydrostatic power
|
| Brakes: | differential hydraulic wet disc
|
| Cab: | Four-post ROPS canopy. Optional cab and air-conditioning.
|
| Transmission: | 12-speed synchronized
|
| Capacity |
| Fuel: | 32 gal
121.1 L
|
| Rear diff.: | 37 qts
35.0 L
|
| Hydraulics |
| Type: | open center
|
| Valves: | 1
|
| Pump flow: | 11.4 gpm
43.1 lpm
|
| Total flow: | 19 gpm
71.9 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Rear lift (at 24"/610mm): | 3,500 lbs
1587 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| Dimensions & Tires |
| Wheelbase: | 93 inches
236 cm (2WD)
|
| | 91.9 inches
233 cm (4WD)
|
| Weight: | 6100 to 7285 pounds
|
| Front tire: | 7.50-16
|
| Rear tire: | 16.9-28
|
| Full dimensions and tires ... |
| 6070 Serial Numbers |
| Location: | Right side of engine adapter flange
|
| 1984: | 1001
|
| 1985: | 1609
|
| Final: | 1972
|
how to read serial numbers...
|
| Electrical |
| Charging system: | alternator
|
| Charging amps: | 72
|
| Battery volts: | 12
|
|
