| Production |
| Manufacturer: | Farmall (a part of International Harvester)
|
| Type: | Row-Crop tractor
|
| Factory: | Rock Island, Illinois, USA
|
| Variants |
| IH 544: | utility tractor
|
| 2544: | industrial tractor
|
| Farmall 544 Power |
| Drawbar (claimed): | 45.5 hp
33.9 kW
|
| PTO (claimed): | 52 hp
38.8 kW
|
| Plows: | 4 (16-inch)
|
| Drawbar (tested): | 44.74 hp
33.4 kW
|
| PTO (tested): | 55.52 hp
41.4 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | power
|
| Brakes: | independent mechanical disc
|
| Cab: | Open operator station. Cab optional with heater.
|
| Transmissions: | 5-speed gear
|
| | 10-speed two-speed power shift
|
| | 5-speed shuttle
|
| | hydrostatic
|
| Photos |
| | Farmall 544 photos... |
| Hydraulics |
| Type: | open center
|
| Valves: | 0 to 2
|
| Tractor hitch |
| Rear Type: | II/I
|
| Type: | IH Fast Hitch
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| Dimensions & Tires |
| Wheelbase: | 90 inches
228 cm
|
| Weight: | 6100 to 7195 pounds
|
| Front tire: | 6.00-16
|
| Rear tire: | 13.6-38
|
| Full dimensions and tires ... |
| 544 Serial Numbers |
| Location: | Serial number plate on the right side of the tractor, on the clutch housing.
|
photo of 544 serial number
| | 1968: | 10250
|
| 1969: | 12541
|
| 1970: | 13585
|
| 1971: | 14507
|
| 1972: | 15262
|
| 1973: | 15738
|
how to read serial numbers...
|
| Electrical |
| Charging system: | alternator
|
| Charging amps: | 55
|
| Gasoline Batteries: | 1
|
| Diesel Batteries: | 2
|
| Gasoline Battery volts: | 12
|
| Diesel Battery volts: | 6
|
| Gasoline Battery AH: | 50
|
| Diesel Battery AH: | 135
|
|
