| Production |
| Manufacturer: | Farmall (a part of International Harvester)
|
| Type: | Row-Crop tractor
|
| Total built: | 65,982
|
| Original price: | $5,500 (1963)
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | manual rack-and-pinion
|
| | hydrostatic power optional
|
| Brakes: | independent mechanical disc
|
| Cab: | Open operator station.
|
| Transmissions: | 5-speed sliding gear
|
| | 10-speed partial power shift
|
| Photos |
| | Farmall 560 photos... |
| Capacity |
| Fuel: | 33 gal
124.9 L
|
| | 37 gal
140.0 L (LP)
|
| Hydraulic system: | 16 gal
60.6 L
|
| Hydraulics |
| Capacity: | 16 gal
60.6 L
|
| Valves: | 1 to 3
|
| Pump flow: | 12 gpm
45.4 lpm
|
| | 17 gpm
64.3 lpm (optional)
|
| Steering flow: | 2.5 gpm
9.5 lpm
|
| Tractor hitch |
| Type: | IH Fast Hitch
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| Dimensions & Tires |
| Wheelbase: | 96 inches
243 cm
|
| | 100 inches
254 cm (Hi-Clear)
|
| Weight: | 6563 to 6785 pounds
|
| Front tire: | 6.00-16
|
| Rear tire: | 12.4-38
|
| 560 Serial Numbers |
| Location: | Clutch housing, right side
|
photo of 560 serial number
| | 1958: | 501
|
| 1959: | 7341
|
| 1960: | 26914
|
| 1961: | 36125
|
| 1962: | 47798
|
| 1963: | 60278
|
| Final: | 66032
|
how to read serial numbers...
|
| Belt Pulley |
| Diameter: | 11 inches
27 cm
|
| Width: | 7.5 inches
19 cm
|
| Electrical |
| Ground: | negative
|
| Charging system: | generator
|
| Charging amps: | 20
|
| Batteries: | 1 (gas)
|
| | 2 (diesel)
|
| Battery volts: | 12 (gas)
|
| | 6 (diesel)
|
|
