| Production |
| Manufacturer: | Farmall (a part of International Harvester)
|
| Type: | Row-Crop tractor
|
| Factory: | Rock Island, Illinois, USA
|
| Total built: | 10,799
|
| Original price: | $13,400 (1976)
|
| Farmall 766 Power |
| Drawbar (tested): | 73.37 hp
54.7 kW
|
| PTO (tested): | 85.45 hp
63.7 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | hydrostatic power
|
| Brakes: | hydraulic dry disc
|
| Cab: | Open operator station. Cab optional.
|
| Transmissions: | 8-speed sliding gear
|
| | 16-speed partial power shift
|
| Photos |
| | Farmall 766 photos... |
| Hydraulics |
| Type: | open center
|
| Pump flow: | 12 gpm
45.4 lpm
|
| Tractor hitch |
| Rear Type: | 2
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540, 1000
|
| Dimensions & Tires |
| Wheelbase: | 102.7 inches
260 cm
|
| Weight: | 10,300 lbs
4672 kg
|
| Front tire: | 9.5L-15
|
| Rear tire: | 18.4-34
|
| Full dimensions and tires ... |
| 766 Serial Numbers |
| Location: | Left side of clutch housing
|
photo of 766 serial number
| | 1971: | 7101
|
| 1972: | 7416
|
| 1973: | 9611
|
| 1974: | 12378
|
| 1975: | 14630
|
| 1976: | 16840
|
how to read serial numbers...
| |
