John Deere 7205J Tractors
 |
|
Power: 205 hp
Date of manufacture : 2010 - 2020 |
| Production |
| Manufacturer: | John Deere
|
| Type: | Row-Crop tractor
|
| Factory: | Montenegro, Brazil
|
| John Deere 7205J Power |
| Engine: | 205 hp
152.9 kW
|
| PTO (claimed): | 174 hp
129.8 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Differential lock: | electro-hydraulic
|
| Steering: | hydrostatic power
|
| Brakes: | hydraulic wet disc
|
| Trailer brakes: | air brake optional
|
| Cab: | Cab standard with air-conditoning.
|
| Transmissions: | 16-speed partial power shift
|
| | 16-speed
|
| Hydraulics |
| Type: | closed center
|
| Pressure: | 3046 psi
210.0 bar
|
| Valves: | 2 to 4
|
| Pump flow: | 32 gpm
121.1 lpm
|
| | 46 gpm
174.1 lpm (optional)
|
| SCV flow: | 30.1 gpm
113.9 lpm
|
| | 44.9 gpm
169.9 lpm (optional)
|
| Tractor hitch |
| Rear Type: | 3/3N
|
| Control: | electronic lower-link sensing
|
| Rear lift (at ends): | 16,670 lbs
7561 kg
|
| | 23,020 lbs
10441 kg (optional)
|
| Rear lift (at 24"/610mm): | 10,140 lbs
4599 kg
|
| | 14,000 lbs
6350 kg (optional)
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | electro-hydraulic wet disc
|
| Rear RPM: | 540/1000
|
| Engine RPM: | 540@1950
1000@1950
|
| Dimensions & Tires |
| Wheelbase: | 112.6 inches
286 cm
|
| Weight: | 17,860 lbs
8101 kg
|
| Front tire: | 16.9-30
|
| Rear tire: | 20.8-42
|
| Full dimensions and tires ... |
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 90
|
| Batteries: | 2
|
| Battery volts: | 12
|
| Battery AH: | 100
|
|
