| Production |
| Manufacturer: | Kioti (a part of Daedong)
|
| Type: | Compact Utility tractor
|
| Factory: | Daegu, South Korea
|
| Original price: | $11,000 (2006)
|
| Kioti LB1914 Power |
| Engine: | 20.5 hp
15.3 kW
|
| PTO (claimed): | 17.1 hp
12.8 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Folding ROPS. Canopy optional.
|
| Transmission: | 8-speed synchronized shuttle
|
| Photos |
| | Kioti LB1914 photos... |
| Hydraulics |
| Type: | open
|
| Pump flow: | 6 gpm
22.7 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift (at 24"/610mm): | 1,323 lbs
600 kg
|
| Power Take-off (PTO) |
| Rear PTO: | transmission
|
| Rear RPM: | 540/1000
|
| Front RPM: | 2800
|
| Dimensions & Tires |
| Wheelbase: | 56 inches
142 cm
|
| Weight: | 2,132 lbs
967 kg
|
| Front tire: | 6-12
|
| Rear tire: | 9.5-20
|
| LB1914 Serial Numbers |
| Location: | On the tractor's transmission housing ahead of the clutch pedal.
|
| 1990: | 600001
|
| 1991: | 700001
|
| 1992: | 800001
|
| 1993: | 900001
|
how to read serial numbers...
| |
