Kioti LK3504 Tractors

Kioti LK3504
Power: 35 hp
Date of manufacture :
1999 - 2002
Production
Manufacturer:Kioti (a part of Daedong)
Type:Compact Utility tractor
Factory:Daegu, South Korea
Kioti LK3504 Power
Engine (gross):35 hp
26.1 kW
PTO (claimed):29 hp
21.6 kW
Kioti LK3504 Engine
Mechanical
Chassis:4x4 MFWD 4WD
Brakes:wet disc
Cab:Foldable ROPS.
Transmission:8-speed synchronized shuttle
Photos
Kioti LK3504 photos...
Hydraulics
Total flow:8 gpm
30.3 lpm
Power Take-off (PTO)
Rear PTO:live (two-stage clutch)
Rear RPM:540/1000
Front RPM:2700
Dimensions & Tires
Wheelbase:65.7 inches
166 cm
Weight:3,170 lbs
1437 kg
Front tire:9.5-16
Rear tire:14.9-24
Full dimensions and tires ...
