Kubota M4970 Tractors

Kubota M4970
Power: 49 hp
Date of manufacture :
1986 - 1988
Production
Manufacturer:Kubota
Type:Utility tractor
Kubota M4970 Power
Engine:49.5 hp
36.9 kW
PTO (claimed):47.5 hp
35.4 kW
Kubota M4970 Engine
Mechanical
Chassis:4x4 MFWD 4WD
Transmission:16-speed
Hydraulics
Pump flow:9.25 gpm
35.0 lpm
Tractor hitch
Rear Type:JISII/I
Rear lift:4189 lbs
1900 kg
Power Take-off (PTO)
Rear RPM:540/1000 (1.375)
Engine RPM:540@2194
1000@2530
Dimensions & Tires
Wheelbase:83.1 inches
211 cm
Weight:5379 lbs
2439 kg
Front tire:8.3-22
Rear tire:12.4-32
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
