LS XJ2025 Tractors

LS XJ2025
Power: 24 hp
Date of manufacture :
0000 - 0000
Production
Manufacturer:LS
Type:Compact Utility tractor
Variants
XJ2025:gear
XJ2025H:hydrostatic
LS XJ2025 Power
Engine (gross):24.4 hp
18.2 kW
Gear PTO (claimed):19.5 hp
14.5 kW
Hydro PTO (claimed):18.5 hp
13.8 kW
LS XJ2025 Engine
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:Two-post folding ROPS.
Transmissions:6-speed gear
 hydrostatic
Hydraulics
Gear Pump flow:6.9 gpm
26.1 lpm
Hydro Pump flow:5.9 gpm
22.3 lpm
Gear Total flow:8 gpm
30.3 lpm
Hydro Total flow:8.5 gpm
32.2 lpm
Gear Steering flow:1.1 gpm
4.2 lpm
Hydro Steering flow:2.6 gpm
9.8 lpm
Tractor hitch
Rear Type:I
Control:position control
Rear lift (at ends):1433 lbs
650 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:independent
Rear RPM:540 (1.375)
Engine RPM:2000
Dimensions & Tires
Wheelbase:59 inches
149 cm
Weight:1609 to 1785 pounds
Electrical
Ground:negative
Charging system:alternator
Charging amps:50
Battery volts:12
