Power: 28 hp Date of manufacture : 2009 - 2010
Production Manufacturer: LS Type: Compact Utility tractor Variants i3030: shuttle i3030H: hydrostatic LS i3030 Power Engine (gross): 28.5 hp 21.3 kW PTO (claimed): 23 hp 17.2 kW LS i3030 Engine Mechanical Chassis: 4x4 MFWD 4WD Steering: hydrostatic power Brakes: wet disc Cab: Two-post ROPS. Transmission: 12-speed synchro shuttle Hydraulics Valves: 0 to 2 Pump flow: 8.2 gpm 31.0 lpm Total flow: 12.3 gpm 46.6 lpm Steering flow: 4.1 gpm 15.5 lpm Tractor hitch Rear Type: I Control: position and draft control Rear lift: 1808 lbs 820 kg Power Take-off (PTO) Rear PTO: independent Rear RPM: 540 (1.375) Mid PTO: optional Mid RPM: 2000 Dimensions & Tires Wheelbase: 65.4 inches 166 cm Weight: 2780 lbs 1261 kg Front tire: 7-14 Rear tire: 11.2-24 Electrical Ground: negative Charging system: alternator Charging amps: 50 Battery volts: 12

LS XU6168	Power: 68 hp	Date of manufacture : 2017 - 2020

LS i28	Power: 28 hp	Date of manufacture : 0000 - 0000

LS i36	Power: 38 hp	Date of manufacture : 0000 - 0000

LS i38	Power: 38 hp	Date of manufacture : 0000 - 0000

LS i3030	Power: 28 hp	Date of manufacture : 2009 - 2010

LS i3030H	Power: 28 hp	Date of manufacture : 2009 - 2010

LS i3040	Power: 38 hp	Date of manufacture : 2009 - 2010

LS i3040H	Power: 38 hp	Date of manufacture : 2009 - 2010
