Power: 34 hp Date of manufacture : 2002 - 2009
Production Distributor: Mahindra Manufacturer: TYM Type: Compact Utility tractor Factory: South Korea Mahindra 3510 Power Engine: 34 hp 25.4 kW PTO (claimed): 28.7 hp 21.4 kW (gear)   28 hp 20.9 kW (hydro) Mahindra 3510 Engine Mechanical Chassis: 4x4 MFWD 4WD Steering: hydrostatic power Brakes: wet disc Transmissions: 12-speed synchomesh shuttle   hydrostatic Photos Mahindra 3510 photos... Hydraulics Type: open center Valves: 1 Gear Pump flow: 7.87 gpm 29.8 lpm Hydro Pump flow: 6.4 gpm 24.2 lpm Gear Steering flow: 3.57 gpm 13.5 lpm Hydro Steering flow: 4.60 gpm 17.4 lpm Tractor hitch Rear Type: I Control: position control Gear Rear lift: 2865 lbs 1299 kg Hydro Rear lift: 2080 lbs 943 kg Power Take-off (PTO) Rear PTO: independent Clutch: electro-hydraulic Rear RPM: 540/1000 (gear)   540 (hydro) Engine RPM: 540@2524 (gear) 1000@2866 (gear) 540@2775 (hydro) Mid PTO: independent (hydro only) Clutch: electro-hydraulic Mid RPM: 2000 Engine RPM: 2000@2650 Dimensions & Tires Weight: 3064 to 3881 pounds 3510 Serial Numbers Location: Serial number on front-left of tractor frame. photo of 3510 serial number Electrical Ground: negative Charging system: alternator Charging amps: 50 Charging volts: 12 Battery volts: 12 Battery AH: 110

Mahindra 3215	Power: 32 hp	Date of manufacture : 2006 - 2008

Mahindra 3316	Power: 33 hp	Date of manufacture : 2008 - 2010

Mahindra 3325	Power: 35 hp	Date of manufacture : 2004 - 2008

Mahindra 3505	Power: 35 hp	Date of manufacture : 1999 - 2002

Mahindra 3510	Power: 34 hp	Date of manufacture : 2002 - 2009

Mahindra 3525	Power: 35 hp	Date of manufacture : 2004 - 2008

Mahindra 3535	Power: 35 hp	Date of manufacture : 2009 - 2019

Mahindra 3540	Power: 40 hp	Date of manufacture : 0000 - 0000

Mahindra 3550	Power: 49 hp	Date of manufacture : 0000 - 0000
