| Production |
| Manufacturer: | Mahindra
|
| Type: | Utility tractor
|
| Original price: | $27,438 (2016 shuttle ROPS )
|
| Original price: | $28,688 (2016 hydrostatic ROPS )
|
| Original price: | $36,375 (2016 shuttle cab )
|
| Original price: | $37,625 (2016 hydrostatic cab )
|
| Mahindra 3540 Power |
| Engine: | 40 hp
29.8 kW
|
| Shuttle PTO (claimed): | 31 hp
23.1 kW
|
| Hydro PTO (claimed): | 30.5 hp
22.7 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Two-post foldable ROPS. Cab available with air-conditioning.
|
| Transmissions: | 12-speed power shuttle
|
| | hydrostatic
|
| Photos |
| | Mahindra 3540 photos... |
| Hydraulics |
| Type: | open center
|
| Rear valves: | 1
|
| Pump flow: | 11 gpm
41.6 lpm
|
| Steering flow: | 5 gpm
18.9 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Control: | position and draft control
|
| Rear lift: | 3090 lbs
1401 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540 (1.375)
|
| Engine RPM: | 540@2404
|
| Dimensions & Tires |
| Weight: | 4367 to 5617 pounds
|
| Front tire: | 9.5-16
|
| Rear tire: | 14.9-24
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| ROPS Charging amps: | 45
|
| Cab Charging amps: | 120
|
| Charging volts: | 12
|
| Battery volts: | 12
|
| Battery AH: | 96
|
|
