McCormick-Deering Super AWD-6 Tractors
 |
|
Power: 0
Date of manufacture : 1953 - 1957 |
| Production |
| Manufacturer: | McCormick-Deering (a part of International Harvester)
|
| Type: | Standard-tread tractor
|
| Factory: | Melbourne, Australia
|
| Variants |
| Super AW-6: | kerosense engine, standard front
|
| Super AWD-6: | diesel engine, standard front
|
| Super AM: | kerosene engine, row-crop front
|
| Super AMD: | diesel engine, row-crop front
|
| McCormick-Deering Super AWD-6 Power |
| McCormick-Deering Super AWD-6 Engine |
| Mechanical |
| Chassis: | 4x2 2WD
|
| Brakes: | differential manual drum
|
| Cab: | Open operator station.
|
| Transmission: | 5-speed
|
| Power Take-off (PTO) |
| Rear PTO: | optional
|
| Rear RPM: | 537
|
| Dimensions & Tires |
| Wheelbase: | 76.5 inches
194 cm
|
| Weight: | 5768 to 7298 pounds
|
| Front tire: | 7.50-16
|
| Rear tire: | 14x30
|
| Full dimensions and tires ... |
| Super AWD-6 Serial Numbers |
| Location: | Right side of tractor on clutch housing.
|
| 1953: | 1755 to 3506
|
| 1954: | 3507 to 6431
|
| 1955: | 6432 to 6507
|
| 1956: | 6508 to 7968
|
| 1957: | 7959 to 8900
|
how to read serial numbers...
|
| Belt Pulley |
| Diameter: | 11 inches
27 cm
|
| Width: | 7.5 inches
19 cm
|
| RPM: | 899
|
| Speed: | 2588 ft/min
788.82 meters/min
|
|
