Power: 60 hp Date of manufacture : 1961 - 1963
Production Manufacturer: Nuffield Factory: Birmingham, England Nuffield 4/60 Power Engine (gross): 60 hp 44.7 kW Engine (net): 57 hp 42.5 kW Drawbar (claimed): 50 hp 37.3 kW PTO (claimed): 55 hp 41.0 kW Belt (claimed): 56 hp 41.8 kW Drawbar (tested): 49.72 hp 37.1 kW PTO (tested): 54.90 hp 40.9 kW Nuffield 4/60 Engine Mechanical Chassis: 4x2 2WD Final drives: spur gear Differential lock: mechanical rear Steering: manual Brakes: independent mechanical expanding shoe Cab: Open operator station. Transmission: 5-speed gear Photos Nuffield 4/60 photos... Hydraulics Type: open center Tractor hitch Rear Type: II/I Control: depth control*Optional Rear lift: 2300 lbs 1043 kg Power Take-off (PTO) Rear PTO: independent Rear RPM: 540 (1.375) Engine RPM: 528@1400 Dimensions & Tires Wheelbase: 78 inches 198 cm Weight: 5689 lbs 2580 kg Front tire: 6.00-16 Rear tire: 11.00-36 Full dimensions and tires ... Belt Pulley Diameter: 10.25 inches 26 cm RPM: 1150 Speed: 3160 ft/min 963.17 meters/min

Nuffield 3/42	Power: 42 hp	Date of manufacture : 1961 - 1963

Nuffield 3/45	Power: 45 hp	Date of manufacture : 1967 - 1969

Nuffield 4/25	Power: 25 hp	Date of manufacture : 1967 - 1969

Nuffield 4/60	Power: 60 hp	Date of manufacture : 1961 - 1963

Nuffield 4/65	Power: 65 hp	Date of manufacture : 1967 - 1969

Nuffield 10/42	Power: 43 hp[P]	Date of manufacture : 1964 - 1966

Nuffield 10/60	Power: 61 hp[P]	Date of manufacture : 1964 - 1967

Nuffield DM-4	Power: 50 hp[B]	Date of manufacture : 1950 - 1961
